Designed for dust collection with high-production equipment such as automated air-blast systems, these EM cartridge collectors increase air flow, provide more filtration area and clean filters automatically.
The filter-cleaning system features a photohelic gauge provided as standard equipment. This unit responds to high and low set points-measured in terms of pressure differential across the filtering material-to activate the jet-pulse cleaning process. Once the pressure limits have been set, these collectors essentially clean themselves.
Machine Options
| Model Number | Blower Assembly | Flow | Static Pressure | Filtration Area | Enclosure Size |
|---|---|---|---|---|---|
| EM2-2 | 5 hp – 7-1/2 hp | 900 to 1200 CFM | 6 to 18 Inch | 528 ft² | 40 x 65 x 150 Inch |
| EM2-4 | 7-1/2 hp – 10 hp – 15 hp | 1600 to 2600 CFM | 6 to 18 Inch | 1056 ft² | 60 x 65 x 150 Inch |
Standard Features
- Intake Area is specifically designed to extend life of interior components and surfaces exposed to abrasive media.
- Horizontal Cartridges are easy to replace, provide large filtration area and capture 99.999% of particles one-half micron or larger.
- Lid for Standard 55-gallon Waste Drum is supplied. Large drum capacity reduces labor and downtime for dust disposal. (Drum not supplied.)
Warranty
BEST WARRANTY IN THE INDUSTRY
Three-years limited on parts and labor
Empire Air-Blast Products
- A complete range of cabinets
- Robotic, turntable and in-line automation
- Blast rooms and blast booths
- Portable blasters
- A full line of parts and accessories
NEVER USE SILICA SAND IN ANY EMPIRE EQUIPMENT
Information subject to change without notice.
